2015-2023 Dodge Charger Flow Series Side Markers (4pc) Install Guide

Ace
Ace
  • Updated


πŸ”§ Tools & Materials Needed

  • Flathead screwdriver

  • T25 Torx bit

  • Ratchet with extension

  • Plastic trim removal tool

  • Zip ties or adhesive clips

  • Optional: jack stands or ramps for better access


πŸ“¦ What’s Included in the Kit

  • 4x Prebuilt Flow Series Smoked LED Side Markers (Front & Rear)

  • 1x Hybrid LED Controller (Bluetooth App + RF Remote)

  • 4x Extension Wires (one per marker)

  • Quick Start Wiring Guide


πŸ› οΈ Installation Steps

1. Test the Side Markers

Before installation, connect each side marker to the controller and power source to ensure all LEDs function correctly

2. Remove Factory Side Markers

Front Side Markers:

  • Turn the front wheels inward to access the inner fender liner.

  • Remove the plastic clips and screws securing the liner using a flathead screwdriver and T25 Torx bit.

  • Gently pull back the liner to expose the side marker.

  • Disconnect the wiring harness and press the retaining tabs to remove the marker.

Rear Side Markers:

  • Access the rear markers by removing the back wheels or fender lining

  • Use a trim removal tool to carefully pry out the side marker.

  • Disconnect the wiring harness.

3. Install New Flow Series Side Markers

  • Connect each new side marker to its corresponding extension wire.

  • Secure the side marker into the fender, ensuring it clicks into place.

  • Route the extension wire through the fender liner, or underneath vehicle or any way you see fit.

4. Route Extension Wires to the Controller

  • Run the front extension wires along the inner fender towards the engine bay.

  • Route the rear extension wires underneath or through vehicle to engine bay.

  • Use zip ties or adhesive clips to secure the wires, keeping them away from moving parts and heat sources.

5. Connect to the Hybrid Controller

  • Mount the Hybrid LED Controller in a dry, accessible location (e.g., engine bay or trunk).

  • Connect each extension wire to the controller's output channels.

  • Connect the controller's power and ground wires to the vehicle's battery or a suitable power source.

  • If utilizing turn signal functionality, connect the controller's input wires to the vehicle's turn signal wires as per the wiring guide.

6. Test and Finalize Installation

  • Turn on the vehicle and test the side markers using the Bluetooth app or RF remote.

  • Cycle through colors and modes to ensure proper functionality.

  • Reinstall any removed liners or panels, ensuring all wires are secured and not pinched


⚑ Wiring Overview

  • Side Marker to Controller: Each side marker connects to the controller via its extension wire.

  • Controller Power: Connect to a 12V power source and ground.

  • Turn Signal Integration (Optional): Connect the controller's input wires to the vehicle's turn signal wires to enable sequential turn signal functionality.


πŸ’‘ Tips for Routing Wires

  • Avoid Heat and Moving Parts: Keep wires away from exhaust components, suspension parts, and any areas with excessive heat or movement.

  • Secure Wires: Use zip ties or adhesive clips to fasten wires along existing harnesses, ensuring a clean and secure installation.


πŸ“± Controller Usage

  • Bluetooth App: Download the RGB Halo Kits app on your iOS or Android device to control colors, modes, brightness, and more.

  • RF Remote: Use the included handheld remote for quick adjustments without accessing your phone.
